ApexMat-S Silica Insulation Needle Mat Roll

Description:

ApexMat-S Silica Mat is made from 100% amorphous silica fibers mechanically bonded through needle-punching.

Unit:

• 1 roll
  • Width: 60"
  • SF per roll:

    • 1.0": 250 SF
    • 0.50": 500 SF
    • 0.25": 900 SF
  • Roll weight
    • 1.0": 180 lbs
    • 0.50": 224 lbs
    • 0.25": 181 lbs
• 6 rolls per pallet

Specifications:

Technical Data Sheet Safety Data Sheet

Properties:

• Color: White
• Nominal Density: 9 lb/ft3 (128 Kg/m3)
• Service Temperature: 1800˚F (982˚C)
• Intermittent Temperature: 2300˚F (1260˚C)
• Melting Point: 3100˚F (1704˚C)


Thermal Conductivity (W/m*K):

• 500°F (260°C): 0.06
• 1000°F (538°C): 0.11
• 1500°F (816°C): 0.20
• 1800°F (982°C): 0.28
